Magnavon Micro Stop Cage Countersinks and Cutters

Chucks (Magnavon part numbers)

1059	1116	1150	1166	1180	1194	1210	1216	1218	1456
1854	2140	2141	2142	2143	2173	2174	2177	2188	2189
2190	2191	2192	2193	2194	2195	2196	2197	2198	2199
2216	2220	2266	2268	2269	2270	2274	2297	2299	2333
2334	2335	2336	2337	2338	2373	2392	2393	2394	2395
2396	2399	2445	2446	2450	2474	2528	2559	2560	2590
2616	2679	2680	2681	2682	2683	2684	2685	2686	2687
2688	2689	2690	2691	2693	2714	2715	2747	2748	2774
2791	2799	2800	2824	2836	2844	2845	2846	2847	2848
2849	2850	2967	2968	2969	2991	2995	2998	2999	3001
3016	3027	3340	3341	3342	3343

Cutters (Magnavon series numbers)

1034

1035

1134

1164

1297

2301

2302

2303

[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09


[Back to Top of page]

Copied from the Magnavon Catalog on 3/17/09

Note: The specifications and information provided on this page are intended for part identification purposes only.
Although we believe them to be correct, dimensions should not be used for part construction or inspection.
